Omron PLC Stretch Wrapping Machine Turntable 1650 Mm Variable Speed Heavy Duty

Detalhes do produto

System control Omron PLC. Photo-eye pallet height sensor. 0-3 top(bottom) and up-down wrap times choose. 312 RPM variable turntable speed by frequency changer. Variable carriage up/down speed. Cycle pause capability. Manual carriage up/down switch. Turntable jog button. Turntable. 1650 mm diameter structural steel plate. 85 mm low profile turntable. Position turntable alignment. Turntable soft start/soft stop, heavy duty chain drive. Rear forklift transportable. Film carriage. Friction brake (variable film tension control). Heavy duty chain carriage lift, calm and safety. Safety stop to avoid foot crush. Options. Ramp. Pneumatic top plate. Packing height: 2800 mm. Turntable diameter: 1800 mm, 2000 mm. Turntable capacity: 2500 kgs, 3000 kgs. Machine color. Technical data. Model no. SZR SW2000E. Max load size L1200 x W1200 x H2400 mm. Packing efficiency 20-40 loads/hour based on load size. Turntable diameter 1650 mm. Turntable height 90 mm. Turntable weight capacity 2000 kgs. Turntable speed 3-12 RPM. Machine weight 600 kgs. Power supply 220V 50Hz 1 phase. Power consumption 1.2 KW. Machine dimension L2625 x W1650 x H2895 mm.
